MDS Series Dovetail Ring Set.

Description Fits MDS Series dovetail bars. Includes two adjustable guidescope rings with large delrin tipped thumb screws and two MDS dovetail clamp adapters. MDS Clamp– The MDS dovetail clamp adapters incorporates a split clamp design that grips the dovetail bar along the entire surface of the clamp and will not dent or scratch the dovetail bar. The dovetail clamp has a large “T” handle locking knob for tool free operation, spring loaded jaws, anodized aluminum and stainless steel construction. Dimensions 1.5″ Long, 1.9″ Wide, .75″ Thick, Weight of each clamp ~3 oz. Adjustable Rings– Includes two adjustable guidescope rings with large delrin tipped thumb screws.  The adjustable rings are CNC machined from 6061 aluminum and have adjustable delrin tipped thumb screws that are  3/8x 24tpi.  The measurements are for the inside diameter of the aluminum ring.  The adjustable rings are available in 75mm, 90mm, 100mm, 125mm and 150mm. 75mm rings are adjustable from 40mm – 70mm. Weight per ring 5oz. 90mm rings are adjustable from 60mm – 80mm. Weight per ring 6oz. 100mm rings are adjustable from 70mm – 90mm. Weight per ring 7oz. 125mm rings are adjustable from 70mm – 110mm. Weight per ring 8oz. 150mm rings are adjustable from 95mm – 135mm. Weight per ring 10oz.
